| cooling | 7,10 kW |
|---|---|
| Heating | 7,30 kW |
| Parameter | Mode/type | - | CH-S24FTXAM-GD |
| Capacity | cooling | kW | 7,1 |
| Capacity | heating | kW | 7,3 |
| ДPower supply | - | - | 220-240V/50Hz/1ph |
| Rated power cold | cooling | kW | 2,03 |
| Rated heat output | heating | kW | 1,87 |
| Airflow rate | - | m³/h | 1000/850/760/580/520/450/400/280 |
| Noise level | IDU | dB(A) | 48/44/41/40/38/36/33/27 |
| Noise level | ODU | dB(A) | 59 |
| Refrigerant type | - | - | R32 |
| Overall dimensions width/height/depth: As packaged: | IDU | mm | 993×311×222 1055×385×298 |
| Overall dimensions width/height/depth: As packaged: | ODU | mm | 958×660×402 1032×456×737 |
| Weight (net/gross) | IDU | kg | 13/15,5 |
| Weight (net/gross) | ODU | kg | 45/49,5 |
| Compressor type | - | - | Rotary |
| Drying | - | l/h | 2,4 |
| Temperature range cold | cooling | °С | `-15~50 |
| Temperature range heat | heating | - | `-25~30 |
| Refrigerant weight | - | kg | 1,4 |
| Liquid pipeline diameter | - | mm/inch | 6,38/1/4″ |
| Gas pipeline diameter | - | mm/inch | 15,88/5/8″ |
| Maximum height difference of pipeline | - | m | 10 |
| Maximum length of the main | - | m | 25 |
| Distance between fasteners | - | m | 570 |
