| Model |
_ |
_ |
CH-HP6.0SIRK5 |
| Power Supply |
_ |
_ |
230VAC, 50HZ |
| Capacity*1 |
Cooling
(floor cooling) |
kw |
6.50 |
| Capacity*1 |
Heating
(floor heating) |
kw |
6.20 |
| Power Input*1 |
Cooling
(floor cooling) |
kw |
1.20 |
| Power Input*1 |
Heating
(floor heating) |
kw |
1.18 |
EER*1
(floor cooling) |
_ |
w/w |
5.40 |
COP*1
(floor heating) |
_ |
w/w |
5.25 |
| Capacity*2 |
Cooling
(For fan coil) |
kw |
6.20 |
| Capacity*2 |
Heating
(Fan coil or Radiator) |
kw |
6.00 |
| Power Input*2 |
Cooling
(For fan coil) |
kw |
1.85 |
| Power Input*2 |
Heating
(Fan coil or Radiator) |
kw |
1.50 |
EER*1
(for Fan coil) |
_ |
w/w |
3.35 |
COP*1
(Fan coil or Radiator) |
_ |
w/w |
4.00 |
| Maximum current |
Heating |
A |
12.00 |
| Cooling |
A |
9.00 |
| Operating electrical current |
Heating |
A |
6.50 |
| Operating electrical current |
Cooling |
A |
4.70 |
| Starting current |
Heating |
A |
1.70 |
| Starting current |
Cooling |
A |
1.70 |
| Water flow rate |
Rated |
m³/h |
1.07 |
| Water flow rate |
Minimum |
m³/h |
0.55 |
| Sound pressure level |
Cooling |
dB(A) |
54.6 |
| Sound pressure level |
Heating |
dB(A) |
54.8 |
Outdoor
dimensions
(W×D×H) |
Outline |
mm |
924×385×746 |
Outdoor
dimensions
(W×D×H) |
Packaged |
mm |
1093×498×905 |
Indoor
dimensions
(W×D×H) |
Outline |
mm |
429×268×935 |
Indoor
dimensions
(W×D×H) |
Packaged |
mm |
1138×533×340 |
| Net weight/ Gross weight |
Indoor |
kg |
50/58 |
| Net weight/ Gross weight |
Outdoor |
kg |
61/69 |
| Connecting pipe |
Gas |
inch(mm) |
1/2(12) |
| Connecting pipe |
Liquid |
inch(mm) |
1/4(6) |
| Refrigerant charge volume |
kg |
1.30 |
| Operating temperature range |
Cooling |
°C |
-15~48 |
| Operating temperature range |
Heating |
°C |
-30~35 |
| Operating temperature range |
Water Heating |
°C |
-30~45 |
