| cooling | 4.75 kW |
|---|---|
| Heating | 4.90 kW |
| Capacity | Cooling | kW | 4.75 |
| Heating | kW | 4.90 | |
| Electric power supply | 220-240V/1Ph/50Hz | ||
| Rated input | Cooling | kW | 1.60 |
| Heating | kW | 1.40 | |
| Energy performance | Cooling | EER | 2.97 |
| Heating | COP | 3.50 | |
| Air Flow | Indoor unit | m³/h | 650 |
| Sound pressure level | Indoor unit | dB (A) | 35/32/30/27 |
| Outdoor unit | dB (A) | 51 | |
| Type of refrigerant coolant | R410a | ||
| Volume of refrigerant coolant | kg | 1.20 | |
| External static pressure | Pa | 0-60 | |
| Weight | Indoor unit | kg | 25 |
| Outdoor unit | kg | 39 | |
| Operation temperature range | Cooling | °C | -15 ... +48 |
| Heating | °C | -15 ... +24 | |
| Liquid pipeline diameter | mm/inch | 6.35/1/4” | |
| Gas pipeline diameter | mm/inch | 12.7/1/2” | |
| Maximum pipeline level difference | m | 15 | |
| Pipeline maximum length | m | 30 | |
| Communication Cords | 2x0.75mm² | ||
| Main power supply area | Outdoor unit | ||
| Number of the strands (power supply) | 3x1. 5mm² | ||
| Factory Freon fill (for the number of the running meters) | m | 7 | |
| Freon per one running meter (surplus. For one running meter) | g/m | 22 | |
