| cooling | 16.00 kW |
|---|---|
| Heating | 19.00 kW |
| Capacity | Cooling | kW | 16.00 |
| Heating | kW | 19.00 | |
| Electric power supply | 380-415V/3Ph/50Hz | ||
| Rated input | Cooling | kW | 5.50 |
| Heating | kW | 5.40 | |
| Energy performance | Cooling | EER | 2.91 |
| Heating | COP | 3.52 | |
| Air Flow | Indoor unit | m³/h | 2600 |
| Sound pressure level | Indoor unit | dB (A) | 47/45/40/37 |
| Outdoor unit | dB (A) | 60 | |
| Type of refrigerant coolant | R410a | ||
| Volume of refrigerant coolant | kg | 4.20 | |
| External static pressure | Pa | 0-150 | |
| Weight | Indoor unit | kg | 55 |
| Outdoor unit | kg | 103 | |
| Operation temperature range | Cooling | °C | -15 ... +48 |
| Heating | °C | -15 ... +24 | |
| Liquid pipeline diameter | mm/inch | 9.53/3/8” | |
| Gas pipeline diameter | mm/inch | 15.88/5/8” | |
| Maximum pipeline level difference | m | 30 | |
| Pipeline maximum length | m | 50 | |
| Communication Cords | 2x0.75mm² | ||
| Main power supply area | Outdoor unit | ||
| Number of the strands (power supply) | 5x1. 5mm² | ||
| Factory Freon fill (for the number of the running meters) | m | 9.5 | |
| Freon per one running meter (surplus. For one running meter) | g/m | 54 | |
