Number of connected units | 1-5 | |||
Capacity | Cooling | kW | 12,10 | |
Heating | kW | 13,00 | ||
|
kW | 4,2 | ||
Energyefficiency | Cooling (SEER) | kW/kW | 7,2 | |
Heating (SCOP) | kW/kW | 4,2 | ||
Water heating (SCOP) | kW/kW | 4,1 | ||
Power supply | 220-240V/50Hz/1~ | |||
Air flow rate | m3/h | 5800 | ||
Sound pressure level | dB (A) | 60 | ||
Sound pressure level heat water supply | dB (A) | 56 | ||
Water range temperature | °C | 35-55 | ||
Heat water consumption | kg | 0,92 | ||
Weight (net/gross) | kg | 73.5/86.5 | ||
Refrigerant | R32 | |||
Refrigerant charge | gram/m | 2,40 | ||
Refrigerant load | gram/m | 20 | ||
Standard length discharge | m | 50 | ||
Connection diameter gas/liquid | mm/inch | 5x 6.35 / 1/4"-9.52 / 3/8" | ||
Temperature range | Cooling | °C | -15~43 | |
Temperature range | Heating | °C | -22~24 | |
Maximum length of the pipeline (total pipeline length / maximum distance to the indoor unit) | m | 100/25 | ||
Max height difference | m | 25 |
